Features and Functions



  • 4-Channel, Class-AB Sound Quality Amplifier

  • Stable into 4 ohms bridged or 2 ohms stereo load

  • PWM MOSFET power supply

  • High end Op-amps and Capacitors

  • Variable FULL / LP / HP Electronic Crossover

  • 0-12dB variable bass boost

  • 4-way protection circuitry

  • Wired remote control (optional)

  • Panel mount RCA connectors





Specifications



  • Power @ 4Ω: 4 x 165 watts

  • Power @ 2Ω: 4 x 275 watts

  • Power @ 4Ω Bridged: 2 x 550 watts

  • THD @ Rated Power  < 0.05%

  • Signal to Noise Ratio > 100dB

  • Frequency Response 10Hz to 30,000Hz ±1dB

  • Input Sensitivity .5v to 8v

  • Dimensions in mm: 190(W) x 62(H) x 444(L) Overall: 190(W) x 62(H) x 479(L)

SKU Z-150.4-II
Shipping Weight 6.0000kg
Shipping Width 10cm
Shipping Height 57cm
Shipping Length 23cm
Shipping Cubic 0.013110000m3
