Features and Functions



  • Mono Class D Linkable, bass amplifier,

  • Stable into 1 Ohm (2 Ohm w/2 amps Linked/Strapped)

  • PWM MOSFET power supply

  • 24 dB Variable low pass (LPF) crossover

  • 12 dB Variable bass boost equalization

  • 0 – 180 degree variable phase shift

  • 24 dB Variable subsonic filter

  • Selectable master and slave operation for Linked (strapped) amplifier operation





Specifications



  • Power @ 4Ω: 450 watts

  • Power @ 2Ω: 700 watts

  • Power @ 1Ω: 1050 watts

  • Linked @ 2Ω: 1800 Watts

  • THD @ Rated Power  < 0.05%

  • Signal to Noise Ratio > 90dB

  • Damping factor: > 350

  • Efficiency: 86%

  • Input Sensitivity .2v to 8v

  • Dimensions in mm: 190(W) x 62(H) x 275(L) Overall: 190(W) x 62(H) x 305(L)

SKU Z-1KDII
Brand ZAPCO
Shipping Weight 4.5000kg
Shipping Width 9cm
Shipping Height 40cm
Shipping Length 22cm
Shipping Cubic 0.007920000m3
