• Features and Functions
    •Adjustable regulated output voltage from 9V~16V
    •Remote panel-mount Volt Meter to monitor the output
    •Up to 100 Amps of current
    •Units are "strappable" to combine up the 4 units, and provide up to 400 Amps of current. Each unit includes the connection cable for strapping multiple supplies
    •Temperature controlled cooling fans
    •Thermal shut-off protection
    •Over-current protection
    •Pulse charging to inhibit battery sulfating (overcharging)
    Specifications
    •Design: Switching Type
    •Input Voltage 220V AC±10%
    •Input Frequency 50Hz~60Hz
    •DC Output Adjustable 9V~16V DC ±0.5V
    •Output Current 100 Amps DC Continuous (Maximum)
    •Line Regulation < ±5%
    •Load Regulation < ±5%
    •Fuse 10A/250V (Input Voltage: 220V)
    •Output Ripple 150 mV RMS
    •Protection Temperature 75°C
    •Overload Protection: UL more than 105 Amps
    •Cable UL 14 AWG
    •Dimensions (mm): 190(W) x 62(H) x 313(L)
SKU Z-PS220I-P100A
Brand ZAPCO
Shipping Weight 6.0000kg
Shipping Width 21cm
Shipping Height 8cm
Shipping Length 40cm
