• •DSP Processor: Cirrus Logic CS47048
    •Power: 150 MHz/32 bit/192 KHz
    •8-Channels IN, 8-Channels OUT
    •ADC: Cirrus Logic CS47048 32 bit/192 KHz
    •ADC Dynamic Range/THD: 108 dB/-98 dB
    •DAC: Cirrus Logic CS8422 24 bit/192 KHz
    •DAC Dynamic Range/THD: 140 dB/-120 dB
    •Low level (Pre)/Sensitivity: 1-5 VRMS
    •High Level (Spk In)/Sens.: 2-20 V
    •Optical Digital IN: 24 bit-192 KHz
    •Coaxial Digital IN: 24 bit-192 KHz
    •Freq. Response (-3dB): 10 Hz - 22.5 KHz
    •S/N Ratio only DSP Digital Input: 110 dBA
    •S/N Ratio only DSP Analog Input: 106 dBA
    •THD+N only DSP Digital Input: 0,002 %
    •THD+N only DSP Analog Input: 0,005 %
    •Crosstalk at 1 Khz only DSP: 90 dB
    •F/R EQ: 1-6 ch Gr. & Par./31 poles
    •Effect EQ: 7-8 ch Gr. & Par./11 poles
    •Mute/Solo: Yes, each channel
    •Time Align. (Range/Steps): 0/15 ms / 0.02 ms
    •Max Delay (Cm/Steps): 515 cm / 0.68 cm
    •Polarity: 0/180°
    •Remote Control included
    •HD-BT Streaming (with optional HD-BT)
    •PC/Display Connection: USB/6-pin Mini DIN
    •Unit Dimensions: 213(W) x 113(L) x 50(H)
SKU DSP-Z8-IV-AT
Brand ZAPCO
Shipping Weight 3.0000kg
Shipping Width 22cm
Shipping Height 8cm
Shipping Length 30cm
